OneRugged M14M

OneRugged M14M

The M14M is designed to revolutionize mobile computing with the Intel® Core™ Ultra processor, featuring innovative triple AI engines (CPU, GPU, and NPU) for enhanced AI-powered performance. Equipped with 16GB memory and 256GB storage, along with dual slots for upgrades, it efficiently handles local AI applications and computational tasks. A 14-inch high-brightness HD screen ensures clarity in any environment, while the rugged design, including a rotating handle, meets IP65 and MIL-STD-810H standards for durability. The Thunderbolt 4 interface, along with additional ports, offers seamless connectivity. Its dual-battery system (53.58Wh + 14.4Wh) and advanced optimization provide extended operation for demanding workflows. The M14M is the perfect solution for global industries requiring high performance and resilience.

AI-Powered Performance
Intel® Core™ Ultra 3D Architecture
Experience the all-new Intel® Core™ Ultra processor, built on Intel 4 process technology. This powerhouse strikes the perfect balance between performance and energy efficiency for industrial AI PC tasks, delivering robust support for demanding computational needs anytime, anywhere.

Innovative Triple AI Engines
Heterogeneous Computing Efficiency
With the dedicated NPU AI acceleration engine working alongside the CPU and GPU, M14M reaches new heights in industrial AI PC efficiency. Whether running local AI large language models or edge applications, seamless deployment and execution are guaranteed.

Expanded Storage Capabilities
Standard 32GB DDR5 & Dual M.2 Slots
Equipped with standard 32GB DDR5 high-speed memory and a 256GB PCIe SSD, the M14M setup significantly boosts responsiveness and industrial AI PC office efficiency. The dual memory and dual storage slots allow for easy upgrades to meet all application needs.

Tough and Portable by Design
Professional AI PC Chassis & Ergonomics
The M14M combines wear-resistant PC/GF materials with multiple layers of craftsmanship, making it resilient in harsh environments. This industrial AI PC features an integrated rotating handle and a front-facing layout for fingerprint and NFC modules, ensuring seamless, efficient work anywhere.


Dimensions: 366.2mmx246.9mmx24.8mm
Weight: TBD
Product Color: Black
Display:
- Size: 14-inch 16:9
- Resolution: 1920*1080
- Brightness: 1000cd/㎡
Touch Panel
- 10-Point Capacitive Screen,
- G+G
- Hardness above 7H
- Scratch-resistant; Supports glove touch

I/O Ports
USB3.2 *1，USB2.0 *2
TYPE-C
∮3.5mm Standard Earphone Jack *1
RJ45 *2 (10M/100M/1000M adaptive)
RS232 *2
HDMI *1
12PIN Pogo Pin
DC19V/3.78A ∮5.5mm power interface *1

NFC: Optional
2D Barcode Scanner: Optional
Processor: Intel® Core™ Ultra
Operating System: Windows 11 PRO
Memory+Storage
- RAM：16GB
- ROM：256GB SSD
Adapter
- AC100~240V, 19V/3.78A 71.82W output US
- Standard Optional: EU Standard
Camera
- Front 5.0MP (USB)
- Rear 13.0MP (mipi)
Battery
- 1300mah/11.1V (14.4WH)
- 4700mah/11.4V (53.58WH)
Sensor: G-Sensor
Fingerprint: Built in, used for power-on login.
WiFi: WIFI6
WAN: 4G, 5G (optional)
Bluetooth: BT5.1
GPS: Supports single GPS or single Glonass, default GPS

Certification
IP65
CE optional FCC,CCC
MIL-STD-810H
Battery: UN3803, MSDS, IEC62133, Aviation, Shipping Report

Rugged Features
MIL-STD-810H: 1.22m drop resistance
Working temperature: -20 °C to 60 °C
Storage temperature: -30 °C to 70 °C
Electrostatic Discharge: ±4kV contact discharge, ±8kV air discharge
Humidity: 95% Non-Condensing

Accessories
Standard: Handle< DC19V/3.78A adapter
Optional: Removable Battery
