Unitree R1 Robot
The new R1 series, designed for research, education, and development, offers advanced mobility and intelligence in a more accessible form factor. EDU models include a powerful add-on computer for demanding projects.
The agile design provides impressive movement capabilities—from 24 to 26 degrees of freedom (DOF). The robot's design allows for a wide range of maneuvers, providing a solid foundation for implementing specialized functions and processes. The Unitree R1 is integrated with large, multimodal visual-lingual models and offers full access to control interfaces for both joints and sensors.
The R1 EDU series features enhanced articulation and research-grade features:
R1 EDU (U1)
R1 EDU (U2)
R1 EDU Pro A (U3)
R1 EDU Pro B (U4)
R1 EDU Pro C (U5)
R1 EDU Pro D (U6)
What are the differences between the R1 robots?
The Unitree R1 Basic is a compact humanoid robot measuring 127 cm in diameter and weighing 35 kg, designed as an entry point into humanoid robotics. It features dual 3D LiDAR, depth cameras, and agile motion control, providing a robust platform for education, demonstrations, and fundamental research in locomotion and perception.
The EDU variants expand upon the basic R1 model. Like the G1 EDU, it includes a second computer for development, with 40 TOPS (Trillion Operations Per Second) for the R1 EDU U1 or 100 TOPS for the EDU U2 to U6.
Common features for all R1 versions:
Height, Width, and Thickness (Standing): 1210 x 357 x 190 mm
Height, Width, and Thickness (Folded): N/A
Weight with Battery: Approximately 25 kg (Basic)
Calf + Thigh Length: 0.675 m
Single Arm Length: 0.435 m
Joint Range of Motion (Max):
- Waist: Y ±150°, R ±30°
- Knee: -10° to +148°
- Hip: Y ±157°, P -168° to +146°, R -60° to +100°
Hollow Connections and Internal Cables: Yes
Joint Encoders: Dual + Single
Cooling System: Localized Air Cooling
Power Supply: Lithium Battery
Base Processing Power: 8-Core High-Speed Processor Performance
Speaker and Microphone Array: Standard
Wi-Fi 6, Bluetooth 5.2: Yes
Battery Life: ~1h
Smart OTA Update: Supported
Accessories:
- Remote Control: Included
- Battery Charger: Included
- Carrying Case: Included
- Smart Battery (Quick Release): Included
Protective Bracket/Gantry: EDU only
Maximum Single Arm Payload: 2Kg
Maximum Knee Torque: N/A
Walking Speed: N/A
Joint Motor: Low-inertia high-speed internal PMSM motor (Permanent Magnet Synchronous Motor, better responsiveness, speed, and heat dissipation)
Joint Bearings: Crossed roller bearings, double ball bearings Hook
R1 BASIC Model
Name: R1
Europe: RB-Unt-166
Programmable Development*: X
Computing Power (TOPS): X
Perception Camera (Binocular): Humanoid
Degrees of Freedom (Total Joints): 24
Degrees of Freedom (Waist): 2
Degrees of Freedom (Shoulder): 5
Degrees of Freedom Head: X
Degrees of Freedom Leg: 6
Hand Model: Aesthetic
Fingers per Hand: X
Degrees of Freedom Per Hand (Total): X
Degrees of Freedom Refraction: X
Controlled Force: X
Touch Sensors: X
R1 EDU U1 Model
Name: R1 EDU Standard
Europe: RB-Unt-167
Programmable Development*: YES
Computing Power (TOPS): 40
Perception Camera (Binocular): Humanoid
Degrees of Freedom (Total Joints): 24
Degrees of Freedom (Waist): 2
Degrees of Freedom (Per Arm): 5
Degrees of Freedom Head: X
Degrees of Freedom Per Leg: 6
Hand Model: Aesthetics
Fingers per Hand: X
Degrees of Freedom Per Hand (Total): X
Degrees of Freedom Refraction: X
Controlled Force: X
Touch Sensors: X
R1 EDU U2 Model
Name: R1 EDU Intelligent
Europe: RB-Unt-200
Programmable Development*: YES
Computing Power (TOPS): 100
Perception Camera (Binocular): Humanoid
Degrees of Freedom (Total Joints): 26
Degrees of Freedom (Waist): 2
Degrees of Freedom (Per Arm): 5
Degrees of Freedom Head: 2
Degrees of Freedom Per Leg: 6
Hand Model: Aesthetics
Fingers per Hand: X
Degrees of Freedom Per Hand (Total): X
Degrees of Freedom Refraction: X
Controlled Force: X
Touch Sensors: X
R1 EDU U3 Model
Name: R1 EDU Pro A
Europe: RB-Unt-201
Programmable Development*: YES
Computing Power (TOPS): 100
Perception Camera (Binocular): Anthropomorphic
Degrees of Freedom (Total Joints): 40
Degrees of Freedom (Waist): 2
Degrees of Freedom (Shoulder): 5
Degrees of Freedom Head: 2
Degrees of Freedom Leg: 6
Hand Model: Dex3-1
Fingers per Hand: 3
Degrees of Freedom Per Hand (Total): 7
Degrees of Freedom Refraction: Thumb 3 / Index Finger 2 / Middle Finger 2
Controlled Force: YES
Touch Sensors: X
R1 EDU U4 Model
Name: R1 EDU Pro B
Europe: RB-UNT-202
Programmable Development*: YES
Computing Power (TOPS): 100
Perception Camera (Binocular): Anthropomorphic
Degrees of Freedom (Total Joints): 40
Degrees of Freedom (Waist): 2
Degrees of Freedom (Shoulder): 5
Degrees of Freedom Head: 2
Degrees of Freedom Leg: 6
Hand Model: Dex3-1
Fingers per Hand: 3
Degrees of Freedom Per Hand (Total): 7
Degrees of Freedom Articulation: Thumb 3 / Index Finger 2 / Middle Finger 2
Controlled Force: YES
Touch Sensors: YES
R1 EDU U5 Model
Name: R1 EDU Pro C
Europe: RB-Unt-203
Programmable Development*: YES
Computing Power (TOPS): 100
Perception Camera (Binocular): Anthropomorphic
Degrees of Freedom (Total Joints): 38
Degrees of Freedom (Waist): 2
Degrees of Freedom (Shoulder): 5
Degrees of Freedom Head: 2
Degrees of Freedom Leg: 6
Hand Model: BrianCo Revo 2
Fingers per Hand: 5
Degrees of Freedom Per Hand (Total): 6
Degrees of Freedom Refraction: --
Controlled Force: --
Touch Sensors: --
R1 EDU U6 Model
Name: R1 EDU Pro D
Europe: RB-Unt-204
Programmable Development*: YES
Computing Power (TOPS): 100
Perception Camera (Binocular): Anthropomorphic
Degrees of Freedom (Total Joints): 38
Degrees of Freedom (Waist): 2
Degrees of Freedom (Shoulder): 5
Degrees of Freedom Head: 2
Degrees of Freedom Leg: 6
Hand Model: Revo 2 Touch
Fingers per Hand: 5
Degrees of Freedom Per Hand (Total): 6
Degrees of Freedom Refraction: --
Controlled Force: --
Tactile Sensors: --
Use Cases and Opportunities
- University Robotics Labs: For research in locomotion, reinforcement learning, perception, human-robot interaction, and AI integration.
- Small R&D teams/startups: For prototyping humanoid applications without the large capital required for high-end robots. - Public engagement/exhibitions: Demonstrating agile movement, demonstrations, and human-robot interactions at science museums or technology fairs.
- Educational/curricular projects: Advanced robotics courses can use the R1 platform to teach motion control, perception, and artificial intelligence.
- Algorithm benchmarking & testing: Developers can implement and test advanced controllers, vision pipelines, or multimodal models on a physical humanoid.
October 16, 2025
Source: Unitree, RobotShop
